Multi-Color LED Light Bars: How They Work and When You Need One

Multi-color LED light bars enable emergency responders, tow operators, and traffic control to switch warning colors based on the situation and immediate need, without changing hardware. When you have a single full-size light bar or traffic advisor stick bar with dual-color LEDs, it can serve as both a warning flasher and a traffic director, depending on which function you activate from the control panel in the cab.

This guide explains the difference between standard and multi-color designs, which vehicle types benefit from these types of light bars, what to know about SAE compliance before buying, and how to match the right product to your operational needs.

How Multi-Color LED Light Bars Work

Traditional LED warning lights use single-color LEDs that are attached to a fixed-color diode. The color you buy is the color you get, and you can’t change it without replacing the light bar. Multi-color units use dual-color LED chips (typically paired within a single optical lens) that can independently display two different colors. The active color is controlled through a switch box or control panel, allowing the operator to make changes as needed.

For example, this multi-color feature means a light bar can run in red/blue for primary emergency warning, then switch the rear traffic advisor section to amber when the operator hits the arrow button. These changes are made from a single control unit, without moving any hardware.

Multi-Color Traffic Advisor Stick Bars

For traffic advisor stick bars, the multi-color function changes how the arrow patterns behave compared to a standard unit:

Standard Design

The color you choose when purchasing the light bar is shown in every function, including the traffic advisor arrow. If you choose red, all patterns (flash modes and directional arrow) operate in red.

Multi-Color Design

Primary warning patterns run in your chosen color (for example, red/clear). When you activate the traffic advisor button, the unit automatically switches to full amber for the arrow sequence, then returns to the primary color when the arrow is deactivated.

This is particularly useful for tow truck operators and construction crews who need amber traffic direction but also carry primary red or blue warning capability on the same bar.

Multi-Color Full-Size Light Bars (36″ and Up)

Full-size light bars are slightly different because of how the traffic advisor modules are positioned within the bar:

Standard Design

Every full-size bar includes a built-in amber traffic advisor as a default. Regardless of the primary color chosen for the front modules, the rear 6 modules in the traffic advisor section are always amber. For example: a red/clear bar has red/clear front modules and the rear arrow stick is amber.

Multi-Color Design

The entire bar, including the rear traffic advisor section, flashes in the primary color when you activate the warning patterns. If you activate the traffic advisor button, the dual-color LEDs in the rear section switch to amber automatically for the directional arrow sequence, then go back to the primary color when deactivated.

This gives you a full warning system: the bar looks and operates consistently in one color, with amber traffic direction available on demand. Our customers typically combine these light bars with a switch box and controller, which means that all functions are consolidated into a single control point in the cab.

Standard vs. Multi-Color: Feature Comparison

Which Vehicle Types Benefit Most from Multi-Color

Multi-color capability is most valuable when a vehicle serves more than one operational role or needs to meet different color requirements in various situations:

SAE Compliance for Multi-Color Light Bars

Multi-color LED units must meet the same SAE certification requirements as single-color products. The governing standards are SAE J845 (omnidirectional, for full-perimeter bars and beacons) and SAE J595 (directional, for surface-mounted stick bars and grille lights). Most active emergency vehicles require Class 1 certification.

Multi-color functionality does not change a product’s SAE class rating. A Class 1 certified bar remains Class 1 in both standard and multi-color modes. Before buying, we recommend that you always verify the SAE class on the product specification. Also, confirm your state’s requirements for your vehicle type.

Color Authorization by Vehicle Type

Amber is the universal non-emergency warning color with the fewest legal restrictions, so it is generally unrestricted across all types of vehicles. Primary warning colors vary by jurisdiction:

Always verify permitted colors with your state’s authority having jurisdiction (AHJ) before finalizing your lighting configuration.

Frequently Asked Questions

What is multi-color functionality on a light bar?

Multi-color functionality uses dual-color LED chips inside a single optical lens, allowing the same bar to emit two different colors. Typically, the chosen color (red, blue, amber, etc.) is used for primary warning functions, but when you activate the traffic advisor button, it will automatically switch the arrow section to amber. You can control all of these functions from a single switch box in the cab of the vehicle.

Do I need multi-color, or will a standard bar work?

A standard bar is the right choice if your vehicle operates in one role and only one primary color is needed, without the use of amber traffic direction as a separate function. Multi-color is worth the upgrade if you work in multiple scenarios. For example, a tow truck that needs red/amber primary warning lights as well as a separate amber arrow stick. Or, you can choose multi-color if you want both functions in a single unit instead of installing two separate bars.

Does multi-color affect the SAE certification?

No. The SAE class rating of a light bar is based on its measured light output and flash rate, not on how many colors it can produce. A multi-color bar carries the same SAE class certification as its single-color equivalent. Always check the product spec sheet for the specific class rating.

What flash rate is required for SAE compliance?

SAE J595 and SAE J845 both require warning lights to operate at 60–120 flashes per minute (FPM). This requirement applies to both primary warning and traffic advisor modes. At SpeedTech Lights, all of our products are tested and certified to meet this requirement in all active modes.

Can I control primary warning and traffic advisor separately?

Yes, and it’s the core benefit of the multi-color design. The primary warning patterns and the traffic advisor arrow are independently controlled from the switch box. Pressing the arrow button activates the amber arrow sequence; releasing it returns the bar to primary warning mode. Both functions can be used simultaneously, depending on the control box configuration.

What traffic advisor directions are available?

Multi-color traffic advisor units support three directional patterns: left-to-right sweep, right-to-left sweep, and center-out split. These patterns are designed to guide approaching traffic around the scene based on whichever direction is needed for the current conditions.

Are multi-color bars available in mini and surface-mount sizes?

Multi-color LED technology is available across SpeedTech Lights’ product lineup, including mini light bars and surface-mount lights. If you need traffic advisor functionality specifically, full-size bars and dedicated traffic advisor stick bars are the best options to consider. Contact our team at SpeedTech Lights to confirm which specific models carry multi-color options.
